Grease & Epoxy
Sil-Free TM
Sil-Free TM 1020 is a metal-oxide-filled, silicone-free synthetic grease
PRODUCT INFORMATION
specially formulated to enhance heat transfer across the interface
between the semiconductor case and the heat sink without the
migration or contamination associated with silicone-based products.
Dry interface case-to-sink thermal resistance is typically reduced
50% to 75% with proper application of Sil-Free TM 1020.
This virtually "no-bleed", high-performance compound will not dry
out, harden, melt, or run, even after long-term continuous exposure
to temperatures up to 200°C. Even in a vacuum atmosphere (10-5
Torr, 24 hours@100°C), Sil-Free TM 1020 exhibits virtually "no bleed"
or evaporation.
ORDERING INFORMATION
Color
Thermal
conductivity
Operating
temperature range
Volume
Weight
Dielectric strength
Consistency
Bleed
Specific gravity
Shelf life
White
0.79 W/(m-°C)
-40°C to +200°C
10 12 Ohm-cm 2.3 ± 0.5
47.5 grams
225 volts/mil
Paste
0.09 max
% after 24hr @ 200°C
2.8 ± 0.2
Indefinite
(unopened)*
Part number
Package
Size
101700F00000G
101800F00000G
101900F00000G
102000F00000G
102100F00000G
Syringe
Tube
Jar
Tube
Jar
43 grams (1.5 oz)
57 grams (2.0 oz)
57 grams (2.0 oz)
143 grams (5.0 oz)
457 grams (16.0 oz)
* It is recommended that the containers be turned over
every 6 months to minimize settling for ease of mixing
Ther-O-Link TM
Ther-O-Link TM is a silicone-based thermal compound that
PRODUCT INFORMATION
cost effectively enhances the heat transfer between a semi-
conductor case and a heat sink. Easy to apply, Ther-O-Link TM
substantially reduces dry interface thermal resistance, while
providing long life under a variety of conditions.
ORDERING INFORMATION
Color
Thermal conductivity
Operating
temperature range
Volume resistivity
Dielectric strength
White
0.73 W/(m-°C)
-40°C to +200°C
1.0 x 10 15 Ohm-cm
250 volts/mil
Part number
100000F00000G
100100F00000G
100200F00000G
Package
Ampule
Syringe
Tube
Size
1 gram (0.03 oz)
35.7 grams (1.25 oz)
57 grams (2.0 oz)
Consistency
Bleed
Specific gravity
Shelf life
Paste
0.6 max
2.8
Indefinite (unopened)*
100500F00000G
100800F00000G
101600F00000G
108000F00000G
132000F00000G
Tube
Tube
Can
Can
Can
143 grams (5.0 oz)
228.6 grams (8.0 oz)
0.45 kg (1 lb)
2.27 kg (5 lb)
9.07 kg (20 lb)
* It is recommended that the containers be turned over
every 6 months to minimize settling for ease of mixing
Ultrastick TM
Aavid's Ultrastick TM is a unique phase-change thermal inter-
PRODUCT INFORMATION
face material that surpasses grease in thermal performance
and long-term stability. This solid, silicone-free, paraffin-
based thermal compound changes phase at 60°C, with a
concurrent volumetric expansion that fills gaps between the
mating surfaces. Ultrastick TM comes in a convenient applica-
tor bar, allowing for neat, fast application to both heat sink
and component surfaces. One cost-effective application
leaves a thin, film-like deposit, providing excellent heat
transfer and low interface thermal resistance.
Temperature range
Volume resistivity
Dielectric strength
Consistency
Bleed
Specific gravity
Color
Thermal resistance
Shelf life
-40°C to +200°C
1.0 X 1.0 15 Ohm-cm
250 volts/mil
Paste
0.6 max
0.28
Opaque White
0.03°C/W per square inch @ 20 psi
0.02°C/W per square inch @ 100 psi
Indefinite*
ORDERING INFORMATION
* Recommended max. storage temperature: 40oC (105oF)
Part number
100300F00000G
Package
Bar
Size
47.5 grams (0.16 oz)
AMERICA
USA Tel: +1 (603) 224-9988 email: info@aavid.com
ASIA
Singapore Tel: +65 6362 8388 email: sales@aavid.com.sg
112
www.aavidthermalloy.com
EUROPE
Italy Tel: +39 051 764011 email: sales.it@aavid.com
United Kingdom Tel: +44 1793 401400 email: sales.uk@aavid.com
Taiwan Tel: +886 (2) 2698-9888 email: sales@aavid.com.tw
